weichai baudouin 12M26C810-18 engine 296-808kW

Weichai M26 series marine diesel engine (296-808kW)

Product advantages

The M26 series products are originated from Moteurs Baudouin (the company has more than 100 years of history, and is a French major supplier of diesel engines and units. It was acquiredby Weichai in 2009 and is now a wholly-owned subsidiary of Weichai Group). The original products have been improved comprehensively through localization development with respect to their performance, featuring low fuel consumption, long overhaul period and high reliability.The product power is within the range of 330-808kW and is widely used in various types of ships, such as cargo ships, offshore fishing boats, public service ships and passenger ships.

Basic Info.

Model NO.12M26C810-18

Engine 4 Stroke

Engine Position Inboard

Condition New

Weight 3570kg

Start The Way Electric Start

Bore-Stroke 150 X150 mm

Displacement 31.8 L

Minimum Fuel Consumption Rate 195g/Kw H

Oil Consumption Rate 0.8g/Kw H

Firing Order 1-12-5-8-3-10-6-7-2-11-4-9

Smoke Intensity Less Than1.0rb

Noise Less Than116dba

Rotation Direction of Crankshaft (Towar Clockwise

Type Four-Stroke, Water-Cooled, in-Line, Wet Cylinder L

Transport Package Plywood

Specification 2446X 1521 X1810 MM

Trademark WEICHAI

Origin Weifang, Shandong, China

HS Code 8408100000

Production Capacity 50 Sets/ Month

Product portfolio

Product Features

· Safe and reliable: It uses cast iron body, grid structure and high-strength one-piece forged steel crankshaft; the seawater pipe is all of cast copper and stainless steel, and the pure copper sea water pump has stronger corrosion resistance; the cooling lubrication system is equipped with an emergency interface.

· Strong power: The power range is wide; the torque reserve is over 20%, and the diesel engine is divided into high and low speed versions, of which the low speed version diesel engine has higher torque value at medium and low speeds, and the high speed version diesel engine has higher torque value at medium and high speeds, which are better adaptive to different ships.

· Fuel economy: The diesel engines are divided into high and low speed versions, of which the low-speed version diesel engine has lower fuel consumption rate at medium and low speeds, and the high-speed version diesel engine has lower fuel consumption rate at medium and high speeds. The fuel consumption rate of the 6-cylinder diesel engines at rated conditions is less than 200g/kW•h, and the rated fuel consumption rate of the 12-cylinder diesel engine less than 210g/kW•h; the highest oil consumption rate is 0.8g/kW•h.

· Strong practicality: It is equipped with a manual oil pump that can be pre-lubricated and drain the used engine oil. The oil cooler and filter are modular in design; the whole engine is compact in structure; a sight glass is set on the side of the engine block to facilitate maintenance.

Warm prompt
Production cycle: 21 working days.
Mode of transport: By seaTerms of payment: 30% down payment, balance settled before delivery.
Packing method: Non-fumigated wood export packing.
Delivery time: 5 working days after receipt of full payment.
Warranty period: One year warranty. If the problem is not caused by human, it can be repaired at the nearest overseas service station. After the warranty period, by virtue of the purchase contract, enjoy more preferential parts service.
Certifications
Enterprise and product certification.
ISO9001, TUV, CE, CCS, LR, GL, DNV, BV, ABS, NK, RS, RINA, KR
