Jinan diesel engine 8190ZLC 400KW diesel engine spare parts


  • jinan diesel engine
  • 8190zlc

8190ZLC jinan diesel engine spare parts




8 in-line marine diesel engines


ModelRated Power(kw/hp)Rated speed(r/min)Specific fuel consumption(g/kw’h)Specific oil consumption(g/kw’h)Overall dimension L*B*H(mm)Net weight(kg)
8190ZLCZ-R720/9801450≤ 204≤ 1.23175*1220*20555200
8190ZLC720/9801450≤ 204≤ 1.23175*1220*20555200
8190ZLCZ-1R600/8201200≤202≤ 1.23175*1220*20555200
8190ZLCZ1-1R600/8201200≤202≤ 1.23175*1220*20555200
8190ZLC-1600/8201200≤202≤ 1.23175*1220*20555200
8190ZLC1-1600/8201200≤202≤ 1.23175*1220*20555200
8190ZLCZ-2R500/6801000≤202≤ 1.23175*1220*20555200
8190ZLC-2500/6801000≤202≤ 1.23175*1220*20555200
8190ZLCZ-3R650/8801300≤202≤ 1.23175*1220*20555200
8190ZLC-3650/8801300≤202≤ 1.23175*1220*20555200
Main technical data
No. and arrangement of cylinders:8-cylinder,in-line
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:47.6L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
