BH12V190

1 15111000 12 EA 气缸套 CYLINDER BLOCK ASSEMBLY

GASKET, :HEAD CYLINDER,F/ GENERATOR JICHAI MODEL:1050

2 15284000 12 EA EKW,S/N:GCV77,GENERATOR JICHAI MODEL:1050 EKW, CYLINDER HEAD ASSEMBLY

3 15554002 8 EA NUT, :HEAD CYLINDER,F/GENERATOR JICHAI1050, CYLINDER BLOCK ASSEMBLY

WASHER, :F/ GENERATOR JICHAI MODEL:1050 EKW,GENERATOR JICHAI

4 15224019 16 EA MODEL:1050 EKW, CYLINDER BLOCK ASSEMBLY

5 15674011 48 EA BRACKET, :F/GENERATOR JICHAI 1050, BRACKET

SEAL, :SLEEVE,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,GENERATOR

6 15348006 48 EA JICHAI MODEL:1050 EKW, CYLINDER BLOCK ASSEMBLY

7 15674012 12 EA BRACKET, :F/GENERATOR JICHAI 1050, CYLINDER BLOCK ASSEMBLY

SEAL, :RING,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,GENERATOR

8 15228036 12 EA JICHAI MODEL:1050 EKW, CYLINDER BLOCK ASSEMBLY

SEAL, :RING,F/ GENERATOR JICHAI MODEL:1050 EKW,GENERATOR JICHAI

9 15298018 24 EA MODEL:1050 EKW, CYLINDER BLOCK ASSEMBLY

SEAL, :RING,F/ GENERATOR JICHAI MODEL:1050 EKW,GENERATOR JICHAI

10 15298019 12 EA MODEL:1050 EKW, CYLINDER BLOCK ASSEMBLY

11 15275000 2 EA PLATE, :THRUST,F/GENERATOR JICHAI 1050, CYLINDER BLOCK ASSEMBLY

12 GB3452.1-23 48 EA O-RING, :SEAL,23.6X3.55,F/GENERATOR JICHAI MODEL:1050, CYLINDER BLOCK ASSEMBLY

13 GB3452.1-56 6 EA O-RING, :SEAL,56X ID,3.55 OD,F/ GENERATOR JICHAI 1640,JICHAI 1640, CYLINDER BLOCK ASSEMBLY

14 GB3452.1-63 2 EA O-RING, :SEAL,63X5.30,F/GENERATOR JICHAI MODEL:1050, O-RING RING

15 GB3452.1 2 EA O-RING, :SEAL,80X3.55 ID,F/GENERATOR JICHAI MODEL:1050, O-RING RING

16 GB3452.1-95 12 EA O-RING, :SEAL,95X2.65,F/GENERATOR JICHAI MODEL: 650, O-RING RING

17 GB3452.1-300 4 EA O-RING, :SEAL,300X5.3,F/GENERATOR JICHAI MODEL:1050, O-RING RING

18 GB3452.1-9 4 EA O-RING, :SEAL,9.5X1.8,F/GENERATOR JICHAI MODEL:1050, O-RING RING

19 GB3452.1-15 5 EA O-RING, :SEAL,15X2.65,F/GENERATOR JICHAI MODEL:1050, O-RING RING

20 GB3452.1-35 2 EA O-RING, :SEAL,35.5X2.65,F/GENERATOR JICHAI MODEL:1050, O-RING RING

21 GB3452.1-37.5 5 EA O-RING, :SEAL,37.5X3.55,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77, O-RING RING

22 GB3452.1-73 5 EA O-RING, :SEAL,73X3.55,F/GENERATOR JICHAI MODEL:1050, O-RING RING

O-RING, :SEAL,77.5X3.55,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,GENERATOR JICHAI MODEL:1050 EKW,

23 GB3452.1-77.5 5 EA  O-RING RING

24 GB3452.1-95.5 1 EA O-RING, :SEAL,95X5.4,F/GENERATOR JICHAI MODEL:1050, O-RING RING

28 15298023 12 EA SEAL, :RING UPPER COVER,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

VALVE, :EXHAUST,F/ GENERATOR JICHAI MODEL:1050

29 16344000 24 EA EKW,S/N:GCV77,GENERATOR JICHAI MODEL:1050 EKW, CYLINDER HEAD ASSEMBLY

30 16344002 24 EA VALVE, :INLET,F/ GENERATOR JICHAI MODEL:1640-1050, INLET VALVE

31 15774000 96 EA COLLET, :SPLIT,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

32 14234012 48 EA SPRING, :SEAT UPPER,F/GENERATOR JICHAI MODEL:1050, SPRING SEAT

33 12954000 48 EA SPRING, :VALVE,F/GENERATOR JICHAI MODEL:1050, SPRING VALVE

35 15298024 24 EA O-RING, :SEAL,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

37 15441000 48 EA GUIDE, :VALVE,F/GENERATOR JICHAI MODEL:1050, GUIDE VALVE

38 15344025 24 EA SEAT, :INLET VALVE,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

39 15344026 24 EA SEAT, :EXHAUST VALVE,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

44 15298026 12 EA O-RING, :SEAL,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

45 15298025 12 EA O-RING, :SEAL,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

46 Q/JC14009.10 12 EA WASHER, :10,F/GENERATOR JICHAI MODELO:1050, WASHER F

47 Q/JC14009-30 60 EA WASHER, :30 NOM,COOPER,F/GENERATOR JICHAI MODEL:1050, WASHER NOM

48 Q/JC14009-42 48 EA WASHER, :42 NOM,COOPER,F/GENERATOR JICHAI MODEL:1050, WASHER NOM

49 Q/JC14009-18 12 EA WASHER, :18 NOM,COOPER,F/GENERATOR JICHAI MODEL:1050, WASHER NOM

50 2032X0001 12 EA VALVE, :ARM SUB-ASSY,F/GENERATOR JICHAI MODEL:1050, VALVE ARM

52 203300000 24 EA ROCKER, :BRIDGE,F/GENERATOR JICHAI MODEL:1050, ROCKER BRIDGE

SUB, :ASSY ROTATION MECHANISM,F/ GENERATOR JICHAI MODEL:1050

54 203400000 48 EA EKW,S/N:GCV77,GENERATOR JICHAI MODEL:1050 EKW, CYLINDER HEAD ASSEMBLY

55 15348011 4 EA O-RING, :SEAL,F/GENERATOR JICHAI MODEL:1050, O-RING RING

56 15348010 2 EA O-RING, :SEAL,F/GENERATOR JICHAI MODEL:1050, O-RING RING

57 15230002 12 EA GASKET, :F/GENERATOR JICHAI MODEL:1050, GASKET F

58 16587004 48 EA BOLT, :F/GENERATOR JICHAI MODEL:1050, BOLT

62 16587001 46 EA BOLT, :F/GENERATOR JICHAI MODEL:1050, BOLT

63 15444010 46 EA BUSHING, :F/GENERATOR JICHAI MODEL:1050, BUSHING

64 15280000 12 EA GASKET, :F/GENERATOR JICHAI MODEL:1050, GASKET F

PIPE, :MAIN EXHAUST SUB ASSY,F/ GENERATOR JICHAI MODEL:1050

68 209800001 1 EA EKW,S/N:GCV77,, PIPE MAIN

69 15220001 2 EA GASKET, :F/GENERATOR JICHAI MODEL:1050, GASKET F

70 15220002 2 EA GASKET, :F/GENERATOR JICHAI MODEL:1050, GASKET F

71 15507000 48 EA NUT, :F/GENERATOR JICHAI MODEL:1050, NUT F

72 16587000 28 EA BOLT, :F/GENERATOR JICHAI MODEL:1050, BOLT

73 16634012 14 EA PLUG, :F/GENERATOR JICHAI MODEL:1050, PLUG F

74 Q/JC14007 2 EA PLUG, :M 16X1.5,F/GENERATOR JICHAI MODEL:1050, PLUG M

75 Q/JC14009-16 2 EA WASHER, :16 NOM,COPPER,F/GENERATOR JICHAI MODEL:1050, WASHER NOM

76 Q/JC14009-24 14 EA WASHER, :24 NOM,COPPER,F/GENERATOR JICHAI MODEL:1050, WASHER NOM

77 210100000 2 EA FILTER,FUEL:F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77, FILTER FUEL

78 GB3452.1.95 2 EA O-RING, :SEAL,95X2.65,F/GENERATOR JICHAI MODEL:1050, O-RING RING

79 GB3452.1.195 2 EA O-RING, :SEAL,195X3.55,F/GENERATOR JICHAI MODEL:1050, O-RING RING

81 GB3452.1-14 13 EA O-RING, :SEAL,14X2.65,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

PUMP, :UNIT INJECTION ASSY,F/ GENERATOR JICHAI MODEL:1050

82 212000001 4 EA EKW,S/N:GCV77,,GENERATOR JICHAI MODEL:1050 EKW, PUMP UNIT

83 216000002 6 EA INJECTOR, :ASSY,F/GENERATOR JICHAI MODEL:1050, INJECTOR ASSY

NOZZLE, :COUPLE SUB ASSEMBLY,F/ GENERATOR JICHAI MODEL:1050

84 216100000 12 EA EKW,S/N:GCV77,,GENERATOR JICHAI MODEL:1050 EKW, NOZZLE COUPLE

85 18444007 12 EA UNDERLAY UNDERLAY

86 GB119 24 EA Pin D3X8 PIN D3X8

87 16704002 12 EA Tappet TAPPET

88 12914018 12 EA PRESSURE ADJUSTING SPRING PRESSURE ADJUSTING SPRING

89 15223019 12 EA Washer WASHER

90 15223020 12 EA Washer WASHER

91 15223021 12 EA Washer WASHER

92 15223022 12 EA Washer WASHER

93 10634000 4 EA INJECTOR BODY INJECTOR BODY

94 13214008 4 EA INJECTOR CONNECTION POLE INJECTOR CONNECTION POLE

95 15224024 12 EA Washer WASHER

96 GB119 6 EA Pin D5X10 PIN D5X10

97 15318002 12 EA O seal ríng O SEAL RÍNG

98 15318001 12 EA O seal ring O SEAL RING

99 15318000 12 EA O seal ring O SEAL RING

PUMP, :WATERPROOF MACHINE,F/ GENERATOR JICHAI MODEL:1050

100 TTG-35 1 EA EKW,S/N:GCV77,,GENERATOR JICHAI MODEL:1050 EKW, PUMP WATERPROOF

PIPE, :CORRUGATED SUB-ASSEMBLY,F/ GENERATOR JICHAI MODEL:1050

103 224500005 2 EA EKW,S/N:GCV77,, PIPE CORRUGATED

107 GB3452.1 2 EA O-RING, :SEAL,80X3.55 ID,F/GENERATOR JICHAI MODEL:1050, O-RING RING

108 SN 3 EA O-RING, :SEAL,95X5.4,F/GENERATOR JICHAI MODEL:1050, O-RING RING

113 GB3452.1-17 36 EA O-RING, :SEAL,17X2.65,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

114 GB3452.1-50 2 EA O-RING, :SEAL,50X5.40,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

115 GB3452.1-30 2 EA O-RING, :SEAL,30X2.65,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

122 Q/JC12003 4 EA O-RING, :SEAL,30X3.1,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

123 GB3452.1-38 1 EA O-RING, :SEAL,38.7X3.55,F/GENERATOR JICHAI MODEL:1050, O-RING RING

124 GB3452.1-12.5 2 EA O-RING, :SEAL,12.5X1.8,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

125 GB3452.1-100 12 EA O-RING, :SEAL,100X3.55,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

126 GB3452.1-11 1 EA O-RING, :SEAL,11.2X2.6,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

O-RING, :SEAL,51.5X3.55,F/ GENERATOR JICHAI MODEL:1050

127 GB3452.1-51.5 2 EA EKW,S/N:GCV77,,GENERATOR JICHAI MODEL:1050 EKW, O-RING RING

128 GB3452.1-150.5 4 EA O-RING, :SEAL,150X5.40,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

129 GB3452.1-20 3 EA O-RING, :SEAL,20X2.65,F/ GENERATOR JICHAI MODEL:1050 EKW,S/N:GCV77,, O-RING RING

130 GB1235-76 1 EA O-RING, :SEAL,71X3.1 ID,F/GENERATOR JICHAI MODEL:1050, O-RING RING

131 218100002 4 EA FILTER,OIL:F/GENERATOR JICHAI MODEL:1050, FILTER OIL

132 3012.36.30 2 EA FILTER,AIR:CARTRIDGE,F/GENERATOR JICHAI MODEL: 1050, FILTER AIR

133 Z12VB.42.90 1 EA SPRING,:CLAMP,F/GENERATOR JICHAI MODEL:1050 - 1640, SPRING CLAMP

134 Z12VB.42.80 1 EA SPRING,:CLAMP,F/GENERATOR JICHAI MODEL:1050-1640, SPRING CLAMP

135 15268002 2 EA GASKET CYLINDER BLOCK ASSEMBLY

136 15228038 1 EA GASKET GASKET

137 15238013 1 EA WASHER CYLINDER BLOCK ASSEMBLY

138 15238014 1 EA WASHER CYLINDER BLOCK ASSEMBLY

139 GB93 28 EA WASHER WASHER

140 15228034 1 EA GASKET GASKET

141 201600000 1 EA OIL SEAL SUBASSEMBLY, FRONT FRAMEWORK CYLINDER BLOCK ASSEMBLY

142 201500001 1 EA OIL SEAL SUBASSEMBLY BACK FRAMEWORK CYLINDER BLOCK ASSEMBLY

143 GB3252.1 1 EA O-RING 300X5.30 O-RING 300X5.30

201000007 1 EA CYLINDER BLOCK ASSEMBLY ( ONLY CYLINDER BLOCK)

144 10111007 1 EA CYLINDER BODY CYLINDER BLOCK ASSEMBLY

145 11313000 1 EA COVER COVER

148 15454000 4 EA SLEEVE, :INJECTOR,F/GENERATOR JICHAI MODEL:1050, CYLINDER HEAD ASSEMBLY

151 203300000 8 EA ROCKER BRIDGE ROCKER BRIDGE

152 203230001 8 EA ADJUSTING SCREW CYLINDER HEAD ASSEMBLY

153 GB894.1 8 EA Spring retainer 40 SPRING RETAINER 40

154 15224021 8 EA Retainer RETAINER

155 203210001 4 EA Rocker arm,exhaust ROCKER ARM ARM EXH

156 8IbGB308 8 EA Steel ball STEEL BALL

157 GB6173 8 EA Nut M14Xl NUT M14XL

158 13214007 8 EA ROCKER ARM POLE ROCKER ARM POLE

159 16804000 4 EA Shaft,rocker arm SHAFT ROCKER

160 10IbGB308 4 EA STEEL BALL STEEL BALL

161 203220001 4 EA Rocker arm,inlet ROCKER ARM ARM INLET

162 GB93 16 EA Washer 12 WASHER 12

163 16574000 16 EA Stud,rocker arm CYLINDER HEAD ASSEMBLY

164 GB6170 16 EA Nut M12 NUT M12

165 16554003 4 EA Stud of flange CYLINDER HEAD ASSEMBLY

166 18154003 4 EA lnjector flang CYLINDER HEAD ASSEMBLY

167 GB849 4 EA Washer 16 WASHER 16

168 GB6175 1 EA Nut M16 NUT M16

170 GB97.1 2 EA Washer 10 WASHER 10

171 GB5782 2 EA BOLT M10 X55 BOLT M10 X55

172 10536000 1 EA UPPER COVER COVER UPPER COVER COVER

173 165A4024 32 EA INTERMEDIATE BOLT INTERMEDIATE BOLT

174 15224013 32 EA Washer WASHER

175 10201000 4 EA INTERMEDIA TE INTERMEDIA TE

176 10211002 4 EA CYLINDER HEAD CYLINDER HEAD

177 16324006 4 EA DEFLATION STOPPER DEFLATION STOPPER

178 16644011 4 EA Plug CYLINDER HEAD ASSEMBLY

179 Q/JC14009 4 EA COPPER WASHER 18 COPPER WASHER 18

180 14254001 4 EA BASE BASE

181 Q/JC14009 4 EA COPPER WASHER 10 COPPER WASHER 10

182 16644010 4 EA Plug CYLINDER HEAD ASSEMBLY

183 15286000 1 EA GASKET GASKET

185 15344023 4 EA CONNECT BUSH CONNECT BUSH

186 10211000 1 EA BASE, :TRANSITION,F/GENERATOR JICHAI MODEL:1050, TRANSITION BASE

187 165C4006 2 EA BOLT BOLT

188 15534004 8 EA Nut NUT

189 GB93 8 EA Washer 10 WASHER 10

190 16624013 8 EA Screw SCREW

191 16624014 12 EA Screw SCREW

196 Q/JC14009 16 EA COPPER WASHER 42 COPPER WASHER 42

197 16644007 16 EA Plug CYLINDER HEAD ASSEMBLY

198 Q/JC14009 20 EA COPPER WASHER 30 COPPER WASHER 30

199 16644008 20 EA Plug CYLINDER HEAD ASSEMBLY

200 16644009 16 EA Plug PLUG

201 18133105 1 EA BAFFLE PLATE I OIL SUMP ASSEMBLY

202 18133078 1 EA BAFFLE PLATE OIL SUMP ASSEMBLY

203 12164000 1 EA CRANKSHAFT CRANKSHAFT

204 16644000 12 EA Plug PLUG

205 GB11 1 EA DOWEL PIN B16X60 DOWEL PIN B16X60

206 16534000 24 EA COUNTERWEIGHT BOLT COUNTERWEIGHT BOLT

207 18414000 2 EA COUNTERWEÍGHT I COUNTERWEÍGHT I

208 GB120 12 EA DOWEL PIN B10X30 DOWEL PIN B10X30

209 18414003 10 EA COUNTERWEIGHT II COUNTERWEIGHT II

210 15405002 12 EA CONNECTING ROD BUSHING CONNECTING ROD BUSHING

211 13124002 12 EA CONNECTING ROD BODY CONNECTING ROD BODY

212 16774002 12 EA DOWEL PIN DOWEL PIN

213 15716000 12 EA CONNECTING ROD BEARING , UPPER CONNECTING ROD BEARING

214 15716001 12 EA CONNECTING ROD BEARING  , LOWER CONNECTING ROD BEARING

215 13114004 12 EA CONNECTÍNG ROD CAP CONNECTÍNG ROD CAP

216 16524000 48 EA CONNECTING ROD BOLT CONNECTING ROD BOLT

217 GB893.1 24 EA Reainer 85 REAINER 85

218 16764000 12 EA Piston pin PISTON PIN

219 205200000 12 EA Piston subassembly PISTON SUBASSEMBLY

HELICAL SPRING OIL RING

220 205200002 12 EA HELICAL SPRING OIL RING SUBASSEMBLY SUBASSEMBLY

221 15324001 12 EA COMPRESSION RING (THIRD) COMPRESSION RING (THIRD)

222 15324002 12 EA COMPRESSION RÍNG (SECOND) COMPRESSION RÍNG (SECOND)

223 15324000 12 EA COMPRESSION RING (TOP) COMPRESSION RING (TOP)

224 11361019 1 EA COVER CYLINDER BLOCK ASSEMBLY

225 11361013 1 EA DIESEL OIL FILTER COVER CYLINDER BLOCK ASSEMBLY

226 11311007 2 EA SIDE COVER CYLINDER BLOCK ASSEMBLY

227 16554000 16 EA BOLT, CYLINDER HEAD CYLINDER BLOCK ASSEMBLY

228 15444000 16 EA SLEEVE CYLINDER BLOCK ASSEMBLY

229 15532001 16 EA NUT CYLINDER BLOCK ASSEMBLY

230 15238015 1 EA WASHER CYLINDER BLOCK ASSEMBLY

231 15233000 12 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

232 15233001 12 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

233 15233002 12 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

234 15233003 6 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

235 15233004 6 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

236 15233005 6 EA ADJUSTING GASKET CYLINDER BLOCK ASSEMBLY

237 201900000 4 EA NAZZLE SUBASSEMBLY CYLINDER BLOCK ASSEMBLY

238 Q/JC11010 8 EA BOLT M10X1.0 CYLINDER BLOCK ASSEMBLY

239 15734000 14 EA CAMSHAFT BEARING METAL CYLINDER BLOCK ASSEMBLY

240 15275003 1 EA RIGHT CAMSHAFT THRUST PLATE CYLINDER BLOCK ASSEMBLY

241 15757001 7 EA LOWER MAIN BEARING METAL CYLINDER BLOCK ASSEMBLY

242 15757000 7 EA UPPER MAIN BEARING METAL CYLINDER BLOCK ASSEMBLY

243 15554000 14 EA MAIN BEARING NUT CYLINDER BLOCK ASSEMBLY

244 15275001 1 EA LEFT CAMSHAFT THRUST PLANTE CYLINDER BLOCK ASSEMBLY

245 16514000 14 EA MAIN BEARING BOLT CYLINDER BLOCK ASSEMBLY

246 15220000 3 EA WASHER CYLINDER BLOCK ASSEMBLY

247 GB3452.1-95 12 EA O-RING, :SEAL,95X30,F/GENERATOR JICHAI MODEL:1050, CYLINDER BLOCK ASSEMBLY

248 Q/JC14008 4 EA NUT M10X1 CYLINDER BLOCK ASSEMBLY

249 Q/JC14033 4 EA COPPER WASHER M12 CYLINDER BLOCK ASSEMBLY

250 GB3452.1-80 2 EA O-RING, :SEAL,80X3.55,F/GENERATOR JICHAI MODEL:1050, CYLINDER BLOCK ASSEMBLY

251 15636000 2 EA ADAPTER CYLINDER BLOCK ASSEMBLY

252 19124001 25 G STEEL WIRE FUZZ CYLINDER BLOCK ASSEMBLY

253 19135002 2 EA STEEL WIRE NET CYLINDER BLOCK ASSEMBLY
