289 Water pump gear PC 0 10   12VB.22.06

290 Flat key PC 0 10   10x28GB/T1096

291 Water pump shaft PC 0 10   12VB.22.01B

292 Flat key PC 0 10   6x22GB/T1096

293 Gear end gasket PC 0 10   B 30 50 GB/T13871

29 4 Gasket 6 holes rubber connection between pump and radiator PC 18 10   12VB.20.23

295 Pad PC 0 thirty   12VB.22.09

296 Rear blade cover PC 0 10   12VB.22.02B

297 Copper washer PC 0 10   12VB.22.19B

298 Blade PC 0 10   12V190T.22.01

299 Mechanical seal for pump PC 0 10   SB － 28

300 Signal line PC 0 4   RSR1-12V

301 Securing the nut PC 2 8   12V.02.35

302 Flat key PC 2 4   12V.02.37

303 Flat key PC 2 4   12V.02.21

304 Washer PC 0 4   12V.02.36

305 Round nut PC 3 4   12V.02.28

306 Closing gasket PC 2 5   12V.02.27

307 Thread oil retaining ring PC 3 4   12V.02.26A

308 Finger PC 0 4   GB/T119.2 4×16

309 Crankshaft oil seal PC 0 4   12V.02.24

310 Crankshaft gear PC 0 4   12VB.02.22

1 12VB.01.146 SEAL GASKET 12

2 12V.01.12 SEAL RING 48

3 12V.01.09 CONNECTING WATER PIPE 48

4 12VB.01.10.20.02 SPRING RING 2

5 125.01.10.20 FILTER ELEMENT HOUSING GOUP 2

6 10Q/JC14009-86 COPPER WASHER 3

7 125.01.10.04 3¨RUBBER PIPE 2

8 12V.01.87 GASKET 6

9 Q/JC14009 COPPER WASHER 1

AJUSTING WASHER, OIL PUMP BRACKET

10 12VB.01.112  2

11 12VB.01.24A LOWER MAIN BEARING METAL 6

12 12VB.01.23A UPPER MAIN BEARING METAL 6

13 12VB.01.54 SIDE COVER GASKET 2

14 12VB.01.20.01 SEAL GASKET GEAR TRAIN END 1

15 PG130x160x15HG4-692 OIL SEAL 1

16 12V.01.54 SHUT DOWN DEVICE GASKET 1

17 12VB.01.139 GASKET 1

18 12VB.01.34 CAMSHAFT BEARING 7

19 12VB.01.47 GASKET, GEAR TRAIN HOOD 1

20 12V.01.14 SEAL RING 36

21 12VB.01.136 SEAL RING 12

22 12VB.01.134 SEAL RING 12

23 12VB.01.02C CYLINDER LINER 12

24 12VB.01.03 CYLINDER HEAD GASKET 12

25 12VB.01.45 GASKET TOP COVER 7

26 45x3.5GB1235-76 ¨O¨ SEAL RING 2

27 24Q/JC14009-86 COPPER WASHER 2

28 12VB.01.79A GASKET 1

29 36Q/JC14009-86 COPPER WASHER 1

30 12VB.01.22A LOWER THRUST MAIN BEARING 1

31 12VB.01.21A UPPER THRUST MAIN BEARING 1

32 12VB.01.25A THRUST PLATE 2

33 223.01.25 THRUST PLATE 2

34 12V.01.61B OIL SEAL RING 1

35 12V.01.59B SEAL GASKET 2

36 12V.01.62B SEAL GASKET FLYWHEEL END 1

37 12V.01.93 PAPPER WASHER 1

38 30GB893-76 INTERNAL RETAINER 1

39 Q/JC14009 COPPER WASHER 1

40 12V.33.02B GASKET 1

41 GB3452.1 ¨O¨ SEAL RING 2

42 Q/JC12003 ¨O¨ SEAL RING 1

43 12VB.03.80.01A CYLINDER HEAD 12

44 12VB.03.00B CYLINDER HEAD ASSEMBLY

45 12V.O3.50.01 BULB HEAD ROCKER ARM 24

46 12VB.03.10.02 BUSHING ROCKER ARM 24

47 12VB.03.80.07 SEAL RING 24

48 12VB.03.80.06 SLEEVE INYECTOR 12

49 12VB.03.51 GASKET 12

50 12VB.03.80.1O PLUG SBASSEMBLY 24

51 12VB.03.80.08 ZINC BLOCK 24

52 12VB.03.80.20 PLUG SBASSEMBLY 24

53 Q/JC14009 COPPER WASHER 30 12

54 12VB.03.80.05 SEAT INLET VALVE 24

55 12VB.03.37A INLET VALVE 24

56 12VB.03.80.04 SEAT EXHAUST VALVE 24

57 12VB.03.22 EXHAUST VALVE 24

58 12VB.03.80.09 ZINC BLOCK 24

59 12VB.03.80.02 VALVE GUIDE 48

60 Z12V.03.17A VALVE SPRING INNER 48

61 Z12V.03.18A VALVE SPRING OUTER 48

62 12V.03.16A SPLIT COLLET 48

63 GB893 INTERNAL RETAINER 25 48
