Welcome to Shandong Hongfan Power Technology Co.,Ltd
Weichai Baudouin 6M33 series diesel engine generator (520kw-740kw)
Main Technical Paraters of 6M33
Product Series | 6M33D572E200 | 6M33D633E200 | 6M33D670E200 | / | 6M33D633E310 | 6M33D725E310 |
| Product Model 50Hz | 6M33D572E200 | 6M33D633E200 | 6M33D670E200 | / | 6M33D633E310 | 6M33D725E310 |
| Product Model 50Hz | 6M33D572E201 | 6M33D633E201 | 6M33D670E201 | / | 6M33D710E201 | 6M33D740E311 |
| Mode | Inline, water-cooled, four-stroke, boost cooling | |||||
| Total Displacement (L) | 19.6 | |||||
| Cylinder Bore × Stroke (mm) | 6-150 x 185 | |||||
| Rated Power (kW) 50Hz | 50Hz 520 | 50Hz 575 | 50Hz 610 | / | 50Hz 570 | 50Hz 675 |
| Rated Power (kW) 60Hz | 60Hz 520 | 60Hz 575 | 60Hz 610 | / | 60Hz 570 | 60Hz 675 |
| Backup Power (kW) 50Hz | 50Hz 572 | 50Hz 633 | 50Hz 670 | / | 50Hz 570 | 50Hz 725 |
| Backup Power (kW) 60Hz | 60Hz 572 | 60Hz 633 | 60Hz 670 | / | 60Hz 570 | 60Hz 740 |
| Speed (r/min) | 1500/1800 | |||||
| Oil Volume (L) | 61 | |||||
| Oil Purity Rate (%) | ≤ 0.3% | |||||
| Starting Mode | Electric start | |||||
| Control Method | Electric control, high-pressure common rail | |||||
| Discharge | / | |||||
| Basic Dimensions (mm) | 2264 x 1349 x 1388 | |||||
| Oil Contamination (kg) | 2110 | |||||
| Speed Regulation | Meets G2 performance level | |||||
| Efficiency | Meets G3 performance level | |||||
The Weichai Baudouin 6M33 series engine is a high-performance diesel engine developed through a collaboration between Weichai Power and Baudouin. This engine is designed for various applications such as commercial vehicles, construction machinery, and marine propulsion systems, offering a combination of high efficiency and reliability.
Applications:
Commercial Vehicles: Includes trucks, buses, and other large transport vehicles, offering strong power output and lower operational costs.
Construction Machinery: Such as excavators and bulldozers, providing reliable performance under tough worksite conditions.
Marine Vessels: Used as a main engine or auxiliary power system for ships, ensuring stable and reliable power output.
Generator Sets: Ideal for emergency power supply and stable electricity generation.
In summary, the Weichai Baudouin 6M33 series engine excels in performance, reliability, fuel economy, and environmental performance, making it a top-tier power solution for various demanding industries.
