Baudouin 6M33G750/5 Diesel Engine 610KW 1500RPM Weichai brand

Basic Data

• Engine Model: 6M33G750/5

• Number of Cylinders / Valves: 6 / 24

• Cylinders Arrangement: In-line

• Bore × Stroke (mm): 150 × 185

• Displacement (L): 19.6

• Thermodynamic Cycle: Diesel 4-stroke

• Cooling System: Liquid (water + 50% antifreeze)

• Injection System: Direct

• Fuel System: Mechanical Pump

• Aspiration: Turbocharged and Aftercooled

• Compression Ratio: 15:1

Flywheel & Crankshaft

• Flywheel Housing: SAE 1

• Flywheel Diameter: 14"

• Number of Teeth on Flywheel Ring Gear: 178

• Inertia of Flywheel (kg/m²): 4.75

• Inertia of Crankshaft (kg/m²): 1.66

Emission & Dimensions

• Emission Standard: N/A

• Overall Dimensions with Radiator (L × W × H) (mm): 2575 × 1440 × 1755

• Engine Dry Weight (kg): 2370

• Engine Wet Weight (Includes Oil & Coolant) (kg): 2525

Product Offerings

Jinan Diesel Engine: Jichai 190 series, 6190, 8190, 12V190, 16V190 diesel and gas engine.

Shengdong Gas Generator: 500kW, 700kW gas generators.

Weichai Engines: 6170Z, 8170Z, CW6200, CW8200, R6160Z, WP12, and WP series.

Weichai Baudouin Series: 6M26, 6M33, 12M26, 12M33, 16M33, 12M55, M26, M33, M55 Series.

Zichai Engines: Z6170, Z8170, 6210, 8210, LB8250, LC8250, ZC6200, Z6180, Z8180, Z6150, 6300, 8300.
